5-AXIS MACHINE CENTERS

1 Matsuura Cublex 35 with 32 pallets, 320 tools, 20,000 RPM spindle
1 Yasda PX-30i with 33 pallets, 306 tools, 20,000 RPM spindle
1 Yasda H40i with 24 pallets, 240 tools, 20,000 RPM spindle
1 Robodrill Alpha-T21iFs, 50 pallets, 21 tools, 24K Spindle. Tsudakoma trunnion

HORIZONTAL MACHINE CENTERS

1 KIWA KNH-426X with 2 Pallets, 120 tool capacity at 12,000 RPM spindle
1 KIWA KH-45g with 6 Pallets, 120 tool capacity at 15,000 RPM spindle
1 KIWA KH-45g with 6 Pallets, 220 tool capacity at 15,000 RPM spindle
1 KIWA KH-45g with 6 Pallets, 240 tool capacity at 15,000 RPM spindle

VERTICAL MACHINE CENTERS

1 Doosan DNM500HS High Speed machining with Full 4th Axis,
   30 tool capacity at 15,000 RPM spindle using Fanuc 32i-A control
1 Doosan DNM500HS High Speed machining with 30 tool capacity
   at 14,000 RPM spindle using Fanuc 0i-A control
2 Doosan DNM400II High Speed Look Ahead with 30 tool capacity
   at 12,000 RPM spindle using Fanuc0i-MD Control and one with Samchully indexer
1 Haas Mini Mill with 10 Tool capacity at 6000 RPM
1 Fadal VMC 4020 with Haas Index Heads with 21 tool capacity
1 Fadal VMC 4020 with Full 4th Axis with 21 tool capacity
2 Fadal VMC 4020 with Full 4th Axis with 30 tool capacity
1 Fadal VMC 4020 with Full 4th Axis with 30 tool capacity and 15,000 RPM spindle
1 Fadal VMC 6030 with Full 4th Axis and Rotary Head with 30 tool capacity

WIRE EDM

1 Fanuc Alpha-C400iA (Travel: X14.6" Y10.6" Z10.0")

QUICK-TURN & PROTOTYPE CNC MILLS

2 ProtoTRAK DPM Quick turnaround CNC/Manual Milling
1 ProtoTRAK M X 3 Manual and CNC Milling

CAD CAM & CMM Systems

Seats of FeatureCAM 2016 3D(2) 2D(1) with 5-axis simultaneous and solids
1 Seat of MasterCAM X7 5-axis Simultaneous
2 Seats of SmartCAM - Advanced Production Milling
1 Seat of Pro/EngineerCreo 3.0
1 Seat of SolidWorks
2 Seats of Auto CAD
4 Seats of PC-DMIS

Enterprise Resource Planning (ERP)

9 Seats of JobBOSS Scheduling and Accounting
   Job login/logout on all PC's using JobBOSS's Workstation Driver & AutoVue
10 CNC machine's spindle uptime monitored by Scytec software

OTHER MACHINING EQUIPMENT

6 Manual Bridgeport Style Milling Machines with Digital Read Outs
1 Brown & Sharp Surface Grinder
1 Ried Surface Grinder
1 Harrison 15" Lathe
1 H. E. S. 18" Lathe
1 Hardinge Chucker
1 Sunnen Honing Machine
1 Vertical Grab Band Saw
1 Vertical Powermatic Band Saw
1 DoAll Automatic Horizontal Band Saw
1 DoAll Manual Horizontal Band Saw
1 SmartSkim: shopwide coolant filtering machine
8 Vibratory Deburring Machines
1 Ultrasonic cleaning machine
1 QL Oven for Annealing Noryl
Various Heli-coil Installation Tools
Miller TIG and MIG Welders. Capable of welding steel, stainless, or aluminum

INSPECTION EQUIPMENT

1 Sheffield 9.9.7 CMM with offline PCDMIS software
1 Hexagon Optiv ClassicModel 321GLtp
1 Portable Romer Arm with laser scanner
1 Elbo Tool video tool presetter for all shop tapers
3 Brown & Sharpe Tesa-Hite Electronic Height Gage - 18" & 24"
1 Mitutoyo Digimatic HD-B 18" Height Gage
3 Granite surface plates Grades A (2) and B(1)
1 Brown & Sharpe Grade A+ Gage Block Set
1 Mitutoyo grade 2 (A+) gage block set
1 Mitutoyo 0"-18" Digital Height Gage
2 Alina .0001, .0005 last word dial indicator
1 Brown & Sharpe 1.0" - 2.0" OD Micrometer
1 Brown & Sharpe 1.0" - 2.0" Depth Micrometer
1 Brown & Sharpe 12" dial caliper
4 Brown & Sharpe Bestest .0005 indicator
1 Brown & Sharpe multi anvil micrometer
1 Deltronic DH216 Optical Comparator
1 Deltronic MPC-5 Digital Readout
1 Deltronic TP25 .0625 Gage Pin Set - .0001 steps
1 Deltronic TP25 .0938 Gage Pin Set - .0001 steps
1 Deltronic TP25 .1250 Gage Pin Set - .0001 steps
1 Deltronic TP25 .1875 Gage Pin Set - .0001 steps
1 Deltronic TP25 .2500 Gage Pin Set - .0001 steps
1 Deltronic TP25 .3750 Gage Pin Set - .0001 steps
1 Mitutoyo 0" - 1.0" Flange Micrometer
1 Mitutoyo .093 - 1.0 V-Anvil Micrometer
12 NSK 0" - 12" in 1" increments OD Micrometer
1 Rahn 18" x 24" granite surface plate
1 Ringmaster 1.2500" dia. ring gage
1 Starrett 1" - 2" thread micrometer
1 Starrett 1" - 2" thread gage micrometer standard
11 Starrett 1"-11" in 1"increments End Measuring Rod
1 Starrett 1.5 - 12.0 Inside Micrometer
1 Starrett 0 - 90 degree Chamfer Gage 7/8 DIA. BASE
1 Starrett 90 - 127 degree Chamfer Gage 7/8 DIA. BASE
1 Starrett 90 - 127 degree Chamfer Gage 1.437 DIA BASE
1 Starrett Radius Gage Set
1 TecLock .001" - 1.0" Dial Indicator
1 Tesa .0005 Dial Indicator
1 Vermont .011 to .060 gage pin set
1 Vermont .061 to .250 gage pin set
1 Vermont .251 to .500 gage pin set
